MICROSTAR + SYSTEM MANUAL • page 12 of 21

Simplex, Inc., 270 Riverside Parkway Suite G Austell, GA 30168 • 678-214-6575 • Fax 678-214-6670

Printed in the USA. • www.simplexdirect.com



FAN BLADES

FAN

PART NO.



BOLT SIZE

FT LBS // IN LBS

13820000 SET SCREW 11.7 // 140

13820500 SET SCREW 11.7 // 140

13821000 SET SCREW 8.3 // 100

13822000 1/4 — 20 7.5 // 90

13823000 1/4 — 20 7.5 // 90

13824000 1/4 — 20 7.5 // 90

13825100 1/4 — 20 7.5 // 90

13826000 1/4 — 20 7.5 // 90

13827500 5/16” 13 // 156

13827600 5/16” 13 // 156

13828000 3/8” 24 // 288

MAIN LOAD BLOCKS- ALL SIZES

CONNECTION

FT LBS // IN LBS

LOAD SIDE 4-14AWG 2.9 // 35

LINE SIDE 500MCM-4/0 31 // 375

3/0-4/0 20 // 240

2/0-6AWG 10 // 120

8AWG 3.3 // 40

CIRCUIT BREAKERS

STYLE

TORQUE

INCH LBS

Cutler-Hammer

1-Phase

14-10 AWG 20

8 AWG 25

6-4 AWG 27

3-1/0 AWG 45

Merlin Gerin

3-Phase

14-1/0 50



APPENDIX C - TORQUE VALUES



CONTACTORS



See torque values on the front of the contactor.



ELEMENTS/TRAYS

TERM/NUT

SIZE



TORQUE

INCH LBS

#6 Rod ends 4

#10 Element Conn. 20

1/4-20 High Voltage Contact Simplex



MOTORS, BRACKETS, BUS BAR CONNECTIONS

BOLT/NUT

SIZE



GRADE

TORQUE

FT LBS // IN LBS

.250 (1/4-20) Grade 5, dry 8 // 96

.250 (1/4-20) Grade 2, dry 5.5 // 66

.312 (5/16) Grade 5, dry 17 // 204

.312 (5/16) Grade 2, dry 11 // 132

.375 (3/8) Grade 5, dry 30 // 360

.375 (3/8) Grade 2, dry 20 // 240

.437 (7/16) Grade 5, dry 50 // 600

.437 (7/16) Grade 2, dry 30 // 360

.500 (1/2) Grade 5, dry 75 // 900

.500 (1/2) Grade 2, dry 50 // 600

.562 (9/16) & up Grade 5, dry 110 // 1320

.562 (9/16) & up Grade 2, dry 70 // 840
